AIR PREPARATION - COMBINATION UNITS
SAVE SPACE, SIMPLIFy INSTALLATION, AND REDUCE POTENTIAL LEAK POINTS with a PURPOSE BUILT COMBINATION UNIT.
We stock a comprehensive range of combination units — from compact two-piece filter/regulator sets through to full FRL assemblies in modular and integrated configurations Available in a variety of port sizes and flow rates to suit general factory use through to demanding industrial environments.
Not sure which combination unit is right for your system? Get in touch with our team at sales@macvalves.co.nz — we're here to help you find the right solution.
KNOCKS COMBINATION units
SERVICE 2 UNIT BG0
Part Number: KS2U-014/8G
Port Sizes: 1/4”
Max Supply Pressure: 12 bar
Temperature Range: -10˚C - +50˚C
Built-in gauge.
SERVICE 2 UNIT BG1, 2, 4
Part Number: KS2U-XXX/XX
Port Sizes: 1/4, 3/8, 1/2, 3/4, 1”
Max Supply Pressure: 16 bar
Temperature Range: -10˚C - +50˚C
Available with or without gauge.
SERVICE 3 UNIT BG0
Part Number: KS3U-014/8G
Port Sizes: 1/4”
Max Supply Pressure: 12 bar
Temperature Range: -10˚C - +50˚C
Built-in gauge.
SERVICE 3 UNIT BG2, 4
Part Number: KS3U-XXX/XX
Port Sizes: 1/2, 3/4, 1”
Max Supply Pressure: 16 bar
Temperature Range: -10˚C - +50˚C
Available with or without gauge.
SHAKO COMBINATION UNITS
COMPOSITE/DIE-CAST - FRL
Part Number: UFR/L-0XXX
Function: Effective air filtration, pressure setting, and quality lubrication
Port Size: 1/8 & 1/4" Mini, 1/4 to 1" Standard & Large
Pressure Range: 0.5 - 10kg f/cm2
Filtration: 5μm, 40μm Optional
Download catalogue
STAINLESS STEEL - FRL
Part Number: USFR/L-0XX
Function: High-pressure use, corrosion and chemical resistance.
Port Size: 1/4" Mini, 1/4 to 1/2" Standard, 3/4 & 1" Large
Pressure Range: 0.5 - 20kg f/cm2 Mini, 0.5 - 30kg f/cm2 Standard/Large
Filtration: 5μm
MASTER PNEUMATIC COMBINATION UNITS
MINIATURE - ALUMINIUM
Part Number: CFDRL55 & CFDRL56
See catalogue for full description.
Download catalogue
SENTRY MODULAR
Part Number: VCFDRL10, VCFDRL11 (1/8" & 1/4")
See catalogue for full description.
Download catalogue
350 SERIES CFRL MODULAR
Part Number: BAGV3A0B6A13
(1/4", 3/8", 1/2")
See catalogue for full description.
Download catalogue
380 SERIES MODULAR
Part Number: AAMV3A0B1A1
(3/8", 1/2" and 3/4")
See catalogue for full description.
Download catalogue
VANGUARD MODULAR - 108D
Part Number: MVCFDRL108D
(1/4", 3/8", 1/2" and 3/4")
See catalogue for full description.
Download catalogue
VANGUARD MODULAR - 108W
Part Number: MVCFDRL108W
(1/4", 3/8", 1/2" and 3/4")
See catalogue for full description.
Download catalogue
SENTRY MODULAR VFDRL10 - ACETAL
Part Number: VFDRL10 (1/8", 1/4")
See catalogue for full description.
Download catalogue
MINIATURE FDRL55 OR 56 - ALUMINIUM/ACETAL
Part Number: FDRL55 and 56 1/8" 1/4")
See catalogue for full description.
Download catalogue
FRL 350 SERIES
Part Number: BAGV1A1B6A13
(1/4”, 3/8”, 1/2”)
See catalogue for full description.
Download catalogue
SERIES 380 MODULAR
Part Number: AAMV1A1B1A1
(3/8", 1/2", 3/4")
See catalogue for full description.
Download catalogue
VANGUARD MODULAR - SIGHT FEED OR WICK FEED LUBRICATOR
Part Number: MVFDRL108D, MVFDRL108W (1/4", 3/8", 1/2", 3/4")
See catalogue for full description.
Download catalogue
HI FLOW VANGUARD - SIGHT FEED OR WICK FEED LUBRICATOR
Part Number: FDRL189D, FDRL189W (3/4" and 1")
See catalogue for full description.
Download catalogue
HI FLOW VANGUARD
Part Number: BFDRL289D
(1 1/4" and 1 1/2")
See catalogue for full description.
