AIR PREPARATION - LUBRICATORS
Delivering the right amount of lubricant at the point of use extends component life, reduces downtime, and keeps your system running as intended.
We stock a comprehensive range of pneumatic lubricators — from compact miniature and modular units for light-duty applications through to high-flow vanguard configurations for demanding industrial environments. All available across a variety of port sizes, flow rates, and feed types to suit your specific requirements.
Not sure which lubricator is right for your system? Get in touch with our team at sales@macvalves.co.nz — we're here to help you find the right solution.
knocks LUBRICATORS
LUBRICATOR BG0
Part Number: KLUB-014
Port Sizes: 1/4”
Max Supply Pressure: 12 bar
Temperature Range: -10˚C - +50˚C
LUBRICATOR BG1, 2, 4
Part Number: KLUB-XXX
Port Sizes: 1/4, 1/2, 3/4, 1”
Max Supply Pressure: 16 bar
Temperature Range: -10˚C - +50˚C
sHAKO LUBRICATORS
COMPOSITE/ALUMINIUM
Part Number: UL-0X
Optional metal bowl.
Function: Oil spray mist ensures good lubrication for machines.
Port Size: 1/8 & 1/4" Mini, 1/4 to 1" Standard/Large
Pressure Range: 0.5 - 10kg f/cm2 Mini, 0.5 - 10kg f/cm2 Standard
STAINLESS STEEL
Part Number: USL-0X
Function: High-pressure, corrosion and chemical resistance.
Port Size: 1/4" Mini, 1/4 to 1/2” Standard, 3/4 & 1" Large
Pressure Range: 0.5 - 20kg f/cm2 Mini, 0.5 - 30kg f/cm2 Standard, 0.5 - 60kg f/cm2 Large
MASTER PNEUMATIC LUBRICATORS
MODULAR SIGHT FEED
Part Number: L350D (1/4", 3/8", 1/2")
Body: Zinc
Ambient/Media Temperature:
Plastic bowl: 4° to 52°C
Metal bowl: 4° to 79°C
Max Inlet Pressure: Plastic bowl: 150 psi Metal bowl: 250 psi
Download catalogue
FULL SIZE MODULAR SIGHT FEED
Part Number: L380D (3/8", 1/2", 3/4")
Body: Zinc
Ambient/Media Temperature:
Plastic bowl: 4° to 52°C
Metal bowl: 4° to 79°C
Max Inlet Pressure: Plastic bowl: 150 psi Metal bowl: 200 psi
Download catalogue
FULL-SIZE VANGUARD MODULAR
Part Number: L28D (1/4, 3/8, 1/2, 3/4")
Body: Zinc
Ambient/Media Temperature:
Plastic bowl: 4° to 52°C
Metal bowl: 4° to 79°C
Max Inlet Pressure: Plastic bowl: 150 psi Metal bowl: 200 psi
Download catalogue
HIGH-FLOW VANGUARD SIGHT FEED
Part Number: L29D (3/4", 1", 1-1/2")
Body: Aluminium
Ambient/Media Temperature:
Plastic bowl: 4° to 52°C
Metal bowl: 4° to 79°C
Max Inlet Pressure: Plastic bowl: 150 psi Metal bowl: 200 psi
Download catalogue
HIGH-FLOW VANGUARD SIGHT FEED
Part Number: BL237D (3/4" to 1-1/2")
Body: Aluminium
Ambient/Media Temperature: 4° to 79°C
Inlet Pressure: 200 psi maximum
MINIATURE WICK FEED
Part Number: L50 (1/8" and 1/4")
Body: Aluminium
Ambient/Media Temperature:
Plastic bowl: 4° to 52°C
Metal bowl: 4° to 66°C
Max Inlet Pressure: Plastic bowl: 150 psi Metal bowl: 200 psi
SENTRY MODULAR WICK FEED
Part Number: L10 (1/8" and 1/4")
Body: Acetal
Ambient/Media Temperature:
Plastic bowl: 4° To 52°C
Max Inlet Pressure: Plastic bowl: 150 psi
Download catalogue
FULL-SIZE VANGUARD MODULAR
Part Number: L28D (1/4, 3/8, 1/2, 3/4")
Body: Zinc
Ambient/Media Temperature:
Plastic bowl: 4° to 52°C
Metal bowl: 4° to 79°C
Max Inlet Pressure: Plastic bowl: 150 psi
Metal bowl: 200 psi
Download catalogue
